Semi Automatic Flute Laminator Machine

Semi Automatic Flute Laminator Machine
Features of the machine:
  • The flip flop style bridge design ensure the washing clean and easily.
  • Automatic feeding for bottom paper, face paper feeding by manual. Easy operation, accuracy transmission.
  • Suitable for A/B/C/D/E/F corrugated cardboard laminating and bottom paper over than 350 gsm cardboard.
  • This machine pressure part adopt suspension lamination style, make the board uniform stress, steady feeding, making the board beautiful and smooth, stress belt can move front and behind, can be suitable to many kinds of paperboard in various size.
  • Main parts of the entire machine adopt the famous company original products, it have long service life and steady function

Technical parameter:

MODEL AM-1000 AM-1300 AM-1450
Max.Sheet Size mm 1000×1100 1300×110 1450×1100
Min.Sheet Size mm 320×450 320×450 320×450
Total Power 7 kW 7 kW 7 kW
Speed 0-90 m/Min 0-90 m/Min 0-90 m/Min
Weight of Top Paperboard (g/m2) ≥200 g/m2 ≥200 g/m2 ≥200 g/m2

Note : Due to continues innovation specification subjected to change without prior notice. Modification reserved, design, weight & specifications not binding due to constant changes & improvements. Accessories shown in the pictures may not be the part of standard euipments.
